CSA
Ultra-Low Resistance Current Sensing Shunt
Our CSA series provides ultra-low resistance voltage monitoring, specifically designed for high wattage applications like battery management systems and DC voltage converters. Its e-beam welded Cu-alloy construction ensures excellent thermal dissipation, making it suitable for thermal management systems. The CSA series caters to a versatile range of applications including consumer electronics, telecommunications, industrial electronics, energy storage, and various commercial sectors.
Characteristics
Composition
Metal Element
Resistance Range
0.2mOhm - 4mOhm
Case Size(s)
2512, 3921, 5931
Power
2W, 2.5W, 3W, 4W, 5W, 6W, 7W, 8W, 9W, 10W, 15W
Terminals
2
TCR
±50ppm/°C, ±70ppm/°C, ±100ppm/°C, ±125ppm/°C, ±175ppm/°C, ±200ppm/°C
Features
Automotive (AEC-Q200)
Current Sense
Tolerance
±1.0%, ±5.0%
Datasheet
*Please review specification for available values within range.
Resources
Visit our resources page to learn more about out products and offerings. Access application notes, research publications, and product profiles here.
Buy from a Distributor
This product is available for purchase from distributors as the D1CSA series. Buy on DigiKey today!
CSA
Ultra-Low Resistance Current Sensing Shunt
Our CSA series provides ultra-low resistance voltage monitoring, specifically designed for high wattage applications like battery management systems and DC voltage converters. Its e-beam welded Cu-alloy construction ensures excellent thermal dissipation, making it suitable for thermal management systems. The CSA series caters to a versatile range of applications including consumer electronics, telecommunications, industrial electronics, energy storage, and various commercial sectors.
Characteristics
Composition
Metal Element
Case Size(s)
2512, 3921, 5931
Terminals
2
Resistance Range
0.2mOhm - 4mOhm
Power
2W, 2.5W, 3W, 4W, 5W, 6W, 7W, 8W, 9W, 10W, 15W
TCR
±50ppm/°C, ±70ppm/°C, ±100ppm/°C, ±125ppm/°C, ±175ppm/°C, ±200ppm/°C
Tolerance
±1.0%, ±5.0%
Features
Automotive (AEC-Q200)
Current Sense
CSA
Ultra-Low Resistance Current Sensing Shunt
Our CSA series provides ultra-low resistance voltage monitoring, specifically designed for high wattage applications like battery management systems and DC voltage converters. Its e-beam welded Cu-alloy construction ensures excellent thermal dissipation, making it suitable for thermal management systems. The CSA series caters to a versatile range of applications including consumer electronics, telecommunications, industrial electronics, energy storage, and various commercial sectors.
Characteristics
Composition: Metal Element
Case Size(s): 2512, 3921, 5931
Terminals: 2
Resistance Range: 0.2mOhm - 4mOhm
Power: 2W, 2.5W, 3W, 4W, 5W, 6W, 7W, 8W, 9W, 10W, 15W
TCR: ±50ppm/°C, ±70ppm/°C, ±100ppm/°C, ±125ppm/°C, ±175ppm/°C, ±200ppm/°C
Tolerance: ±1.0%, ±5.0%
Features:
Automotive (AEC-Q200)
Current Sense
Datasheet
CSA Series Specification*
*Please review specification for available values within range.
Buy from a Distributor
This product is available for purchase from distributors as the D1CSA series. Buy on DigiKey today!
| Image | Series | Distribution Series | Description | Composition | Case Size(s) | Terminals | Minimum Resistance | Maximum Resistance | TCR | Tolerance | Power | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | WRL-L4 | D1WRL-L4 | 4 Terminal Symmetrical Footprint Current Sense Resistors | Metal Foil | 1206, 2512 | 4 | 0.5 mOhms | 100 mOhms | ±30ppm/°C, ±50ppm/°C, ±75ppm/°C, ±100ppm/°C | ±0.3%, ±0.5%, ±1.0% | 0.333W, 0.5W, 1W | View Series |
 | KN | General Purpose Thin Film Resistors | Thin Film | 0201, 0402, 0603, 0805, 1206, 1210, 2010, 2512 | 2 | 2.49 Ohms | 1.5 MOhms | ±10ppm/°C, ±15ppm/°C, ±25ppm/°C, ±50ppm/°C | ±0.1%, ±0.25%, ±0.5%, ±1.0% | 0.05W, 0.063W, 0.125W, 0.1W, 0.25W, 0.5W, 0.75W | View Series | |
| CSA | D1CSA | Ultra-Low Resistance Current Sensing Shunt | Metal Element | 2512, 3921, 5931 | 2 | 0.2mOhm | 4mOhm | ±50ppm/°C, ±70ppm/°C, ±100ppm/°C, ±125ppm/°C, ±175ppm/°C, ±200ppm/°C | ±1.0%, ±5.0% | 2W, 2.5W, 3W, 4W, 5W, 6W, 7W, 8W, 9W, 10W, 15W | View Series |
| KN-A | Automotive Grade General Purpose Thin Film Resistors | Thin Film | 0402, 0603, 0805, 1206 | 2 | 4.7 Ohms | 1.5 MOhms | ±10ppm/°C, ±15ppm/°C, ±25ppm/°C, ±50ppm/°C | ±0.1%, ±0.25%, ±0.5%, ±1.0% | 0.063W, 0.125W, 0.1W, 0.25W | View Series | |
 | WEL | D1WEL | Long Side Wrapped Electrode General Purpose Current Sense Resistors | Metal Foil | 0508, 0612, 0815, 0830, 1020, 1225, 1530, 1836, 2043 | 2 | 0.5 mOhms | 100 mOhms | ±50ppm/°C, ±100ppm/°C, ±150ppm/°C | ±0.5%, ±1.0%, ±3.0% | 1W, 1.5W, 2W, 3W, 4W, 5W | View Series |
| WEL | D1WEL | Short Side Wrapped Electrode General Purpose Current Sense Resistors | Metal Foil | 0603, 0805, 1206, 2010, 2512, 4320, 4527 | 2 | 2 mOhms | 700 mOhms | ±50ppm/°C, ±75ppm/°C, ±100ppm/°C | ±0.5%, ±1.0% | 0.5W, 0.75W, 1W, 1.5W, 2W, 3W, 4W | View Series |
| WEL | D1WEL | Automotive Grade Short Side Wrapped Electrode Current Sense Resistors | Metal Foil | 0603, 0805, 1206, 2010, 2512 | 2 | 3 mOhms | 570 mOhms | ±50ppm/°C, ±100ppm/°C | ±0.5%, ±1.0% | 0.5W, 0.75W, 1W, 1.5W, 2W | View Series |
| WEL | D1WEL | Automotive Grade Long Side Wrapped Electrode Current Sense Resistors | Metal Foil | 0508, 0612, 0830, 1020, 1225 | 2 | 1 mOhms | 100 mOhms | ±50ppm/°C, ±100ppm/°C | ±0.5%, ±1.0% | 1W, 1.5W, 2W, 3W | View Series |
 | TFA | TFA | Automotive Grade Thick Film Resistors | Thick Film | 0402, 0603, 0805, 1206, 1210, 1812, 2010, 2512 | 2 | 1 Ohms | 10 MOhms | ±100ppm/°C, ±400ppm/°C | ±0.1%, ±0.5%, ±1.0%, ±2.0%, ±5.0% | 0.063W, 0.125W, 0.1W, 0.25W, 0.5W, 0.75W, 1W | View Series |
 | TFAS | TFAS | High Grade Anti-Sulfur Thick Film Resistors | Thick Film | 0201, 0402, 0603, 0805, 1206, 1210, 1812, 2010, 2512 | 2 | 1 Ohms | 10 MOhms | ±100ppm/°C, ±400ppm/°C | ±0.5%, ±1.0%, ±5.0% | 0.05W, 0.063W, 0.125W, 0.1W, 0.25W, 0.5W, 0.75W, 1W | View Series |
 | WKL | D1WKL | Non-Wrapped Electrode General Purpose Current Sense Resistors | Metal Foil | 0508, 0603, 0612, 0805, 0815, 0830, 1020, 1206, 1225, 1530, 1836, 2010, 2043, 2512, 4320, 4527 | 2 | 1 mOhms | 700 mOhms | ±50ppm/°C, ±100ppm/°C | ±0.5%, ±1.0% | 0.5W, 0.75W, 1W, 1.5W, 2W, 3W, 4W, 5W | View Series |
 | MPC | D1MPC | Low Profile Current Sense Resistors | Metal Foil | 0201, 0402, 0603, 0805, 1206 | 2 | 1 mOhms | 50 mOhms | ±50ppm/°C, ±75ppm/°C, ±100ppm/°C, ±150ppm/°C, ±200ppm/°C | ±0.5%, ±1.0% | 0.25W, 0.333W, 0.5W, 1W | View Series |
 | MPA | D1MPA | High Power Current Sense Resistors | Metal Element | 1206, 2512 | 2 | 0.5 mOhms | 56 mOhms | ±50ppm/°C, ±75ppm/°C, ±100ppm/°C, ±150ppm/°C | ±0.5%, ±1.0% | 1W, 2W, 3W | View Series |
 | KU | Low Ohms Metal Film Resistors | Metal Film | 0201, 0402, 0508, 0603, 0612, 0805, 1020, 1206, 1210, 1225, 2010, 2512 | 2 | 10 mOhms | 10 Ohms | ±50ppm/°C, ±100ppm/°C, ±150ppm/°C, ±200ppm/°C | ±0.25%, ±0.5%, ±1.0%, ±2.0%, ±5.0% | 0.005W, 0.05W, 0.063W, 0.125W, 0.1W, 0.25W, 0.2W, 0.4W, 0.5W, 0.75W, 1W, 1.5W, 2W, 3W | View Series | |
 | CPA0612 | D1CPA0612 | 4 Terminal Automotive Grade Long Side Electrode Current Sense Resistor | Metal Foil | 0612 | 4 | 0.5 mOhms | 25 mOhms | ±50ppm/°C, ±100ppm/°C, ±150ppm/°C, ±200ppm/°C | ±0.5%, ±1.0% | 1W | View Series |
 | CPC0306 | D1CPC0306 | 4 Terminal Long Side Electrode Current Sense Resistors | Metal Foil | 0306 | 4 | 1 mOhms | 50 mOhms | ±50ppm/°C, ±100ppm/°C, ±150ppm/°C | ±0.5%, ±1.0% | 0.333W | View Series |
| KGAS | High Grade Anti-Sulfur Automotive Grade Thick Film Resistors | Thick Film | 0402, 0603, 0805, 1206, 1210, 1218, 1812, 2010, 2512 | 2 | 1 Ohms | 10 MOhms | ±100ppm/°C, ±400ppm/°C | ±0.5%, ±1.0%, ±5.0% | 0.063W, 0.125W, 0.1W, 0.25W, 0.5W, 0.75W, 1W | View Series | |
 | CPA-W | CPA-W | 4 Terminal Long Side Electrode Current Sense Resistor | Metal Foil | 1225 | 4 | 0.5 mOhms | 25 mOhms | ±50ppm/°C, ±100ppm/°C | ±0.5%, ±1.0% | 2W | View Series |
